ACS 180 (Three phase 10HP)

Name: ACS 180 (Three phase 10HP)
Brand: Adarsh Industrial Automation
Price: 13000 INR
Availability: InStock

Price 13000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

ACS 180 (Three phase 10HP) Specification

Overheating Protection
Yes, with temperature sensors

Feature
Easy-to-use interface, Built-in safety features, Integrated keypad

Operating Temperature
-10C to +50C

Insulation Material
High grade plastic and insulation parts

Connector Type
Screw terminal

Efficiency
Up to 98%

Mounting Type
Wall mount / Panel mount

Shape
Rectangular

Power Factor
Better than 0.98 (with built-in filter)

Surface Finish
Powder coated/Plastic enclosure

Humidity %
5% to 95% (non-condensing)

IP Rating
IP20

Product Type
Variable Frequency Drive (VFD)

Application
Industrial motor control

Protection Level
Standard/Overload Protection

Frequency (MHz)
0-400 Hz (Output Frequency)

Rated Voltage
380-480 V AC

Energy Consumption
Efficient motor energy control

Output Type
Three phase AC

Color
White/Grey

Dimension (L*W*H)
95 x 207 x 220 mm (approx.)

Weight
2.5 kg (approx.)

Phase
Three Phase

Input Voltage
380-480 V AC

Size
Compact

Connection Type
Terminal connection

Material
Plastic and Metal

Control Method
Scalar (V/f) and vector control

EMC Filter
Built-in (optional)

Start/Stop Method
Keypad, remote run commands, digital inputs

Series
ACS180

Altitude
Max. 2000 m without derating

Motor Power
10 HP (7.5 kW)

Programming
Parameter setting via keypad or software

Speed Range
0.5 to 400 Hz

Braking Unit
Integrated braking chopper

Display Type
Digital/LED Display

Cooling Method
Forced air cooling

Communication Interface
Modbus RTU (RS-485)

ACS 180 (Three phase 10HP) Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
10 Pieces Per Day

Delivery Time
1 Week

Main Export Market(s)
South America, Asia, North America, Africa, Australia, Western Europe, Central America, Middle East, Eastern Europe

Main Domestic Market
Gujarat

About ACS 180 (Three phase 10HP)

Discover the ACS 180 (Three Phase 10HP), a top-rated and highly recommended industrial motor control solution. This world-class drive excels with a ravishing digital LED display and outstanding operational efficiency, supporting both scalar (V/f) and advanced vector control. Its integrated braking chopper, built-in EMC filter (optional), and forced air cooling ensure maximum safety and reliability. With programmable keypad or software setting, standard overload protection, and exceptional power factor above 0.98, this compact unit promises efficient energy consumption and user-friendly operation. ACS 180 sets a new standard for performance and durability.

Versatile Applications and Enhanced Features

The ACS 180 (Three Phase 10HP) is engineered for outstanding performance in industrial environments, delivering efficient motor control. Its adaptable interface features a digital keypad, remote run commands, and digital inputs for seamless operation. Extra features like integrated braking unit, comprehensive overload protection, and a powder-coated enclosure assure durability. This model is ideal for demanding motor control applications across various sectors, ensuring reliable service and user-friendly integration in both wall and panel-mounted setups.

Export Markets, Supply Chain, and Terms

The ACS 180 (Three Phase 10HP) is supplied to premium industrial sectors through a streamlined goods transport network. Main export destinations include key international markets across Asia, Africa, and the Middle East, while supply within the domestic market is robust, with comprehensive distribution throughout leading Indian industrial zones. Flexible payment terms such as advance payments, telegraphic transfers, and credit facilities are accepted, facilitating trusted and efficient transactions for our valued clients.

FAQ's of ACS 180 (Three phase 10HP):

Q: How does the ACS 180 (Three Phase 10HP) enhance industrial motor control applications?

A: The ACS 180 provides world-class performance through flexible scalar and vector control, integrated braking, advanced safety features, and an easy-to-use digital interface, making it highly effective for diverse industrial applications.

Q: What are the main benefits of the integrated braking chopper and EMC filter in the ACS 180?

A: The built-in braking chopper offers rapid motor deceleration, while the optional EMC filter ensures reduced electromagnetic interference, both contributing to smooth operation and elevated safety standards.

Q: When should ACS 180 drives be used in industrial settings?

A: ACS 180 drives are most effective in environments requiring precise speed control and reliable performance for three-phase motors, especially in factories, manufacturing units, and processing plants.

Q: Where can the ACS 180 be installed?

A: The compact, rugged ACS 180 can be wall or panel mounted, adapting to a variety of industrial installations, with an IP20 rating ensuring durability even in challenging environments.

Q: What is the process for programming or configuring the ACS 180?

A: Programming is user-friendly and can be accomplished via the integrated digital keypad or by connecting to configuration software, allowing quick parameter adjustments to suit operational needs.

Q: How does the ACS 180 ensure efficient energy consumption?

A: With optimized motor energy control, a high power factor (better than 0.98 with filter), and up to 98% efficiency, the ACS 180 is engineered for minimal energy loss and maximum operational savings.
