ACS 880

Name: ACS 880
Brand: Adarsh Industrial Automation
Price: 35000.0 INR
Availability: InStock

Price 35000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ACS 880 Specification

Feature
Support for Various Fieldbus Protocols, Integrated Safety Features, Built-in EMC Filter

Connector Type
Screw Terminal

Shape
Rectangular

Insulation Material
Industrial Grade Insulated Components

Mounting Type
Wall Mount

Power Factor
>0.98

IP Rating
IP21/UL Open, Upgradable to IP55

Efficiency
Up to 98%

Surface Finish
Matte Finish

Operating Temperature
-10C to +50C without derating

Humidity %
5-95% non-condensing

Product Type
Variable Frequency Drive (VFD)

Application
Industrial Automation, Pump and Fan Control, Conveyors

Protection Level
Overcurrent, Overvoltage, Undervoltage, Short Circuit, Ground Fault Protection

Frequency (MHz)
0-500 Hz (Output Frequency)

Rated Voltage
380-480V AC

Energy Consumption
High Efficiency, Reduced Energy Consumption Depending on Load

Output Type
AC Motor Output

Color
Black with Blue Label

Dimension (L*W*H)
Approx. 370 x 180 x 230 mm (varies by model)

Weight
Approx. 6-15 kg (depending on frame size)

Phase
Three Phase

Input Voltage
380-480V, 3-phase

Size
Frame sizes R1 to R7

Material
High-Quality Plastic and Metal

Connection Type
Terminal Block

Power Range
0.75 kW to 500 kW (Model Dependent)

Startup Wizard
Integrated Startup Assistant

Display Type
Multilingual Graphic Display Panel

Cooling Type
Internal Fan Cooling

Fieldbus Options
Profibus DP, EtherNet/IP, Modbus TCP, PROFINET IO, DeviceNet

Communication Interface
Ethernet, Profibus, Modbus, CANopen

Motor Control
Support for Induction, Synchronous Reluctance, and Permanent Magnet Motors

Programming
PC Tool for Drive Configuration (Drive Composer)

Maintenance
Predictive Maintenance Features, Diagnostic Capabilities

Control Method
Direct Torque Control (DTC)

Braking
Built-in Brake Chopper (in selected models)

Standards Compliance
IEC/EN 61800-5-1, IEC 61000-6-2/4

ACS 880 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
10 Pieces Per Day

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
Gujarat

About ACS 880

We are a trusted supplier of premium-quality Industrial Automation Products, offering reliable performance, high efficiency, and long services life.

The ABB ACS880 is a premium industrial drive series engineered for maximum reliability and high-performance motor control. As part of ABBs "all-compatible" portfolio, it offers flexible configuration and seamless integration into complex automation systems across global industries.

Key Properties

Precise Control: Utilizes ABBs proprietary Direct Torque Control (DTC), providing exceptionally fast and accurate torque and speed regulation without requiring encoders in most applications.
Robust Construction: Designed for harsh conditions with coated circuit boards as standard, advanced IGBT protections, and a long 9-year maintenance interval.
Integrated Safety: Comes with built-in Safe Torque Off (STO) functionality (SIL 3/PL e) to protect personnel and machinery.
Versatility: Supports virtually all AC motor types, including induction, permanent magnet, and synchronous reluctance motors.
Energy Efficiency: Includes built-in energy calculators, regenerative drive options, and ultra-low harmonic variants to minimize waste and grid impact.

Typical Applications

The ACS880 is widely used in heavy-duty industrial processes, including:

Material Handling: Cranes, conveyors, winches, and elevators.
Processing: Extruders, mixers, centrifuges, and test benches.
Flow Control: Pumps, fans, and compressors in demanding environments.
Specialized Sectors: Oil and gas, marine, mining, cement, chemicals, and pulp and paper.

Advanced Motor Control and Versatility

The ACS 880 is engineered for seamless integration in diverse industrial environments. Its unique Direct Torque Control (DTC) ensures precise and dynamic torque and speed regulation for a variety of motors. With support for induction, synchronous reluctance, and permanent magnet motors, users benefit from unmatched flexibility across multiple applications, including pump and fan systems, conveyors, and complex automation systems.

User-Friendly Operation and Configuration

Enhanced with a multilingual graphic display panel and an integrated startup assistant, the ACS 880 greatly simplifies commissioning and daily operation. The included Drive Composer PC tool offers intuitive drive configuration, enabling users to tailor drive operation for specific process requirements efficiently. Predictive maintenance and diagnostic features minimize downtime and optimize operational reliability.

Robust Connectivity and Compliance

The ACS 880 provides comprehensive communication options, supporting Ethernet, Profibus, Modbus, CANopen, and a range of fieldbus protocols like EtherNet/IP and PROFINET IO. This ensures straightforward integration into modern industrial networks. Built-in EMC filters, multiple safety features, and strict adherence to IEC/EN standards guarantee safe and reliable operation in demanding environments.

FAQ's of ACS 880:

Q: How does Direct Torque Control (DTC) benefit industrial applications in the ACS 880?

A: Direct Torque Control (DTC) in the ACS 880 enables accurate and responsive control of motor speed and torque without the need for encoders. This translates to enhanced process reliability, reduced energy consumption, and improved performance in demanding industrial automation, conveying, pump, and fan applications.

Q: What motors are compatible with the ACS 880 drive, and how does it handle different types?

A: The ACS 880 supports induction, synchronous reluctance, and permanent magnet motors. Its advanced control algorithms automatically adapt to these motor types, offering efficient and precise operation across a wide range of industrial processes.

Q: When should predictive maintenance features be utilized with the ACS 880 drive?

A: Predictive maintenance should be used continuously to monitor drive and motor health. The ACS 880 provides real-time diagnostics to predict potential issues early, helping users schedule maintenance proactively, thereby reducing unplanned downtime and extending equipment life.

Q: Where can the ACS 880 drive be installed, considering its IP ratings and mounting options?

A: The drive can be wall-mounted in environments that meet its IP21 or UL Open standard, suitable for most indoor industrial locations. For harsher or dustier sites, the protection can be upgraded to IP55, ensuring safe installation in a broader range of settings.

Q: What is the process for configuring the ACS 880, and which tools are available?

A: Configuration is streamlined with the integrated startup assistant and the Drive Composer PC tool. These tools guide users through parameter setup, network integration, and safety configuration, allowing efficient and error-free commissioning.

Q: How do the ACS 880's communication interfaces enhance industrial connectivity?

A: With support for Ethernet, Profibus, Modbus, CANopen, and additional fieldbus protocols like EtherNet/IP and PROFINET IO, the ACS 880 easily integrates into complex industrial networks. This promotes interoperability and offers straightforward integration with a variety of automation systems.

Q: What are the primary benefits of choosing the ACS 880 in terms of energy efficiency and protection?

A: The ACS 880 delivers up to 98% efficiency and incorporates built-in features such as overcurrent, overvoltage, undervoltage, short circuit, and ground fault protection. This safeguards your investment and ensures optimal energy usage, resulting in cost savings and enhanced operational reliability.
