Selec RC100 Rate Indicator

Get a Price/Quote

MOQ : 1 Unit

Selec RC100 Rate Indicator Specification

Measuring Range
1 to 9999 (counts/min, Hz, etc.)

Connectivity Type
Terminals

Usage & Applications
Industrial Process Automation, Rate/Speed Indication, Flow and Frequency Measurement

Features
Programmable Input Type, Programmable Decimal Point, High Speed Counting

Output
Optional Relay/Transistor/Analog Output

Switch Type
Keypad Type

Display
4 digit, 7-segment LED

Installation Type
Panel Mount

Protection Level
Front IP54

Mounting Type
Flush Mount

Phase
Single Phase

Current
< 180 mA

Sensor Type
Digital Pulse Input

IP Rating
IP54 (Front)

Frequency
Up to 10 KHz

Product Type
Rate Indicator

Operating Temperature
0C to 55C

Working Temperature
0C to 55C

Input
NPN/PNP/Contact or Potential free contact, 3-30V DC

Application
Speed/RPM/Flow/Batch Counting Rate Measurement

Supply Voltage
85-270V AC/DC

Accuracy
0.03% of F.S.

Dimension (L*W*H)
96 x 48 x 52 mm

Weight
Approx 250g

Humidity
< 95% RH non-condensing

Programmable Parameters
Decimal Point, Hysteresis, Output Logic

Response Time
100 ms

Display Color
Red

Cutout Size
92 x 44 mm

Storage Temperature
-20C to 70C

Material
ABS Plastic Housing

Selec RC100 Rate Indicator Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Selec RC100 Rate Indicator

Discover the Selec RC100 Rate Indicator, a rare and sterling example of industrial measurement mastery. This uncommon masterpiece is available for a limited time at a clearance sale price-don't miss your chance to buy a precision device designed for process automation and speed indication. Its robust ABS plastic housing, red LED display, and fast 100 ms response make it ideal for a wide range of applications. The Selec RC100 features programmable parameters, high-speed counting, and versatile output options, offering remarkable reliability and accuracy for critical operations.

Unlock Superior Accuracy and Versatility

The Selec RC100 Rate Indicator stands out as a top choice for industrial process automation. With its programmable input type, high-speed counting, and decimal point options, it ensures accurate rate, speed, and flow measurements. Suitable for use in speed/RPM detection, batch counting, and frequency monitoring, its versatility makes it an indispensable tool for manufacturers, suppliers, and traders seeking dependable and efficient automation solutions.

Seamless Sample Request and Fast Delivery

Experience the Selec RC100 firsthand with sample availability for evaluation. Our efficient transportation network ensures prompt packing & dispatch, reducing your wait time. Expect delivery within a short period after order confirmation. Our sample policy is customer-friendly, allowing easy trial before final purchase. Take advantage of our sale price on the RC100, making this advanced indicator more accessible for those seeking quality at a competitive rate.

FAQ's of Selec RC100 Rate Indicator:

Q: How do I use the Selec RC100 Rate Indicator in industrial applications?

A: To use the Selec RC100, simply mount it on your panel, connect the required digital pulse input, and configure programmable parameters like decimal point and output logic as per your measurement needs for rate/speed/flow.

Q: What is the display type and visibility of the Selec RC100?

A: The Selec RC100 features a clear, 4-digit, 7-segment red LED display, ensuring high visibility even in challenging industrial environments.

Q: When can I expect delivery after buying the Selec RC100?

A: Once your order is confirmed, we prioritize quick packing and dispatch. Delivery typically occurs within a short timeframe, depending on your location and mode of transportation.

Q: Where can the Selec RC100 be installed?

A: Designed for panel and flush mounting, the RC100 fits securely in environments requiring precision measurement, including manufacturing plants, automation facilities, and process monitoring stations.

Q: What benefits does the Selec RC100 Rate Indicator offer?

A: With high accuracy (0.03% F.S.), fast 100 ms response, and robust IP54 front protection, the RC100 provides reliable and precise measurements essential for optimizing industrial processes.

Q: How do I request a sample of the Selec RC100 Rate Indicator?

A: Contact your supplier or trader to inquire about sample availability. Our sample policy is designed for ease, allowing you to evaluate the RC100 before purchase.
